| Dimensions |
?171.5 x 33 mm (?6.8 x 1.3") |
| WiFi Standard |
WIFi 7 |
| Spatial Streams |
4 |
| Coverage Area |
115 m² (1,250 ft²) |
| Max. Client Count |
200+ |
| Uplink |
2.5 GbE |
| Mounting |
Ceiling, Wall (Lite Mount Included) |
| Power Method |
PoE |
| MIMO |
|
| 5 GHz |
2 x 2 (DL/UL MU-MIMO) |
| 2.4 GHz |
2 x 2 (DL/UL MU-MIMO) |
| Max. Data Rate |
|
| 5 GHz |
4.3 Gbps (BW240) |
| 2.4 GHz |
688 Mbps (BW40) |
| Antenna Gain |
|
| 5 GHz |
5 dBi |
| 2.4 GHz |
4 dBi |
| Max. TX Power |
|
| 5 GHz |
24 dBm |
| 2.4 GHz |
23 dBm |
| Max. BSSIDs |
8 per Radio |
| Supported Data Rates |
|
| 802.11be (WiFi 7) |
7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240) |
| 802.11ax (WiFi 6) |
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) |
| 802.11ac (WiFi 5) |
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) |
| 802.11n |
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
| Wireless Meshing |
? |
| Band Steering |
? |
| 802.11v BSS Transition Management |
? |
| 802.11r Fast Roaming |
? |
| 802.11k Radio Resource Management (RRM) |
? |
| Advanced Radio Management |
? |
| Passpoint (Hotspot 2.0) |
? |
| Captive Hotspot Portal |
|
| Custom Branding Landing Page |
? |
| Voucher Authentication |
? |
| Payment-Based Authentication |
? |
| External Portal Server Support |
? |
| Password Authentication |
? |
| Guest Network Isolation |
? |
| Private Pre-Shared Key (PPSK) |
? |
| WiFi Speed Limiting |
? |
| Client Device Isolation |
? |
| WiFi Schedules |
? |
| RADIUS over TLS (RadSec) |
? |
| Dynamic RADIUS-assigned VLAN |
? |
| Max. Power Consumption |
13W |
| Supported Voltage Range |
42.5–57V DC |
| Networking Interface |
(1) 2.5 GbE RJ45 port |
| Weight |
313 g (11 oz) |
| Management |
Ethernet |
| Enclosure Material |
UV-stabilized polycarbonate |
| Mount Material |
UV-stabilized polycarbonate, galvanized steel (SGCC) |
| LEDs |
|
| System |
White/Blue |
| Channel Bandwidth |
HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 (MHz) |
| Ambient Operating Temperature |
-30 to 40° C (-22 to 104° F) |
| Ambient Operating Humidity |
5 to 95% noncondensing |
| NDAA Compliant |
? |
| Certifications |
CE, FCC, IC, SRRC, Anatel: 02143-25-08356 |
| Application Requirements |
|
| UniFi Network |
Version 9.0.114 and later |
| Mobile App |
iOS™ version 10.20.2 and later Android™ version 10.21.7 and later |
